Description:

• Can support AC and DC input. Non-existent power supply polarity problems
• Ultra-high voltage scope, support 15-160V DC Input. support 12-110V AC input
• Ultra-high-power control. Max 5A current
• Except the board inside a PWM speed control, can also support an external PWM signal input speed control, external PWM input requirements: level 3.5-12V VPP, the frequency of 1K-5KHZ, in particular apply in MCH3 spindle speed control.
• Support Motor with Resistance >2 Ohm
• Note: When work with AC Motor, power cannot higher than 110V, 90V or lower was suggested to use.
• Size (LxWxH): Approx.7.6cm x 4.9 cm x 6.5cm / 2.99" x 1.93" x 2.55"

Package Includes:

• 1 x Motor Speed Driver
